IP65 16cores Outdoor Fiber Optic Enclosures Buckle Lock FATB-0416

IP65 16cores Outdoor Fiber Optic Enclosures Buckle Lock FATB-0416

Product Details:

Place of Origin: China
Brand Name: FOCABLE
Certification: RoHS Compliant, SGS Certificate, ISO Certificate
Model Number: Fiber Access Terminal Box FATB-0416

Payment & Shipping Terms:

Minimum Order Quantity: 10PCS
Packaging Details: 1PCS/Carton
Delivery Time: 3-5days
Supply Ability: 10000pcs/month
Get Best Price Contact Now

Detail Information

Reinforced Adapter: 24pcs SC/UPC Or 24pcs SC/APC Port: 16 Ports
IP Protection Level: IP65 Protection Level Fiber: 120 Fibers
Quality Control: 100% Test Before Shipping Splitter: 1*8 Or 1*16 Splitter Can Be Installed
High Light:

16cores Outdoor Fiber Optic Enclosures

,

IP65 Outdoor Fiber Optic Enclosures

,

Buckle Lock Fiber Termination Box

Product Description

Fiber Access Termination Box FATB-0416 16 Cores 2mm 4mm 7mm Output Ports Can be Chosen



Fiber access termination box FATB-0416 is able to hold up to 16 subscribers. It is used as a termination point for the feeder cable to connect with drop cable in FTTx network system. It integrates fiber splicing, splitting, distribution, storage and cable connection in one solid protection box.



Features
● Water-proof design with IP65 Protection level.
● Integrated with flap-up splice cassette and adapter holder.
● Maximum 24F splice capacity, stainless anti-rust bolts and nuts.
● Easy for maintainance and expansion.
● Fiber bend radius control more than 40mm.
● 180 degree access with buckled lock structure.
● 2pcs of 1*8 mini tube type PLC splitter can be installed
● 16pcs of mechanical ports for 3-7mm drop cable.

Configuration
Fiber Access Terminal FATB-0416 Parameter
Material
Size
Max Capacity
Reinforced Adapter
Weight
Color
PC+ABS
AxBxC(mm)
Splice 120 Fibers
PLC splittter
24pcs SC/UPC
1.85kg
Grey/Black
340x220x95


2pcs of 1x8(SC)
or 24pcs SC/APC
Application
● Wall-mounted installation
● Pole-mounted installation
● Aerial-hanging installation
● Suitable for 2*3mm indoor FTTH drop cable an outdoor 4-7mm figure-8 self-supporting drop cable



Standard Accessories
Splice cassette and cable management tool, installation nuts and bolts, protection sleeves, cable tube, key, wrench, rubber seal for cable entrance.



Optional Accessories
Pole mounted kits
